Product Information :

Name :
CV300
Category :
  1. เครื่องจักร, อุปกรณ์เกี่ยวกับเครื่องจักร, เครื่องมือกล
Sub - Category :
  1. Temperature Controller (Others)
Brand :
Hanyoung
Product Type :
  1. สินค้า, ผลิตภัณฑ์

Product Detail :

- RS422/485 Line Drive auto control
- Convert RS232 signal to RS422/485 signal
- Built in electrical insulation/protection device
- between RS232 and RS422/485


Specification

Model CV300
Power 9 V, 300 mA d.c Adapter (1.3 Ø d.c Jack)
Communication speed 2400 ~ 115200 bps
Communication distance 1.5km max and possible to connect max 256 devieces
Safety 1/2 circuit insulationm built in the surge protective device,
automatically forms ± 15 KV ESD Protection Line Drive signal
Function setting
2 wires/4 wires, usage of the built in terminating, resistance, full duplex/half duplex setting
Possible
Connection method
RS232 → DB-9 Female (possible to connect directly to the serial port of PC),
RS422/485 → method of inserting communication wire to ther 4 pin terminal block.
Switch setting 6 Pin Piano Type Dip-Switch
Case material Made of plastic
Weight Body : 60 g, Adapter : 300 g
Dimension 52 × 90 × 20 mm
